Solar Panel
Solar Panel ZXI8-BD132 695-730W
ZNSHINE ZXI8-BD132 Series is a high-performance N-Type Monocrystalline Bifacial PV module delivering up to 730 Wp with a maximum efficiency of 23.50%. Featuring Half-Cell, Double Glass, and PU Composite Frame technology, it provides high resistance to PID, corrosion, heat, and humidity, while maintaining reliable performance under low-light conditions. Designed for demanding outdoor environments, the module combines high power output, durability, safety, and a sleek natural-black appearance.
Weight
38.5±1 kg
Mechanical Data
| Solar cells | N-type Monocrystalline |
|---|---|
| Cells orientation | 132 (6×22) |
| Module dimension | 2384×1303×30 mm (With Frame) |
| Glass | 2.0 mm+2.0mm, High Transmission, AR Coated Heat Strengthened Glass |
| Junction box | IP 68, 3 diodes |
| Cables | 4 mm², +300mm,-200mm or Customized Length(with connectors) |
| Connectors | MC4 compatible or MC4-EVO2 |
| Fire safety class | Class A+A |
| Datasheet | Download Datasheet (PDF) |
Tersedia untuk Proyek EPC
