Solar Panel
Solar Panel ZXI8-BD120 630-670W
ZNSHINE ZXI8-BD120 Series is a high-performance N-Type Monocrystalline Bifacial PV module with a power output of up to 670 Wp and a maximum efficiency of 23.67%. Featuring Half-Cell, Double Glass, and PU Frame technology, the module can deliver up to 25% additional power generation from the rear side, while providing excellent durability in harsh outdoor environments and enhanced performance under low-light conditions. It is backed by a 12-year product warranty and a 30-year output guarantee
Weight
33.5±1 kg
Mechanical Data
| Solar cells | N-type Monocrystalline |
|---|---|
| Cells orientation | 120 (6×20) |
| Module dimension | 2172×1303×30 mm (With Frame) |
| Glass | 2.0 mm+2.0mm, High Transmission, AR Coated Heat Strengthened Glass |
| Junction box | IP 68, 3 diodes |
| Cables | 4 mm², +300mm,-200mm or Customized Length(with connectors) |
| Connectors | MC4 compatible or MC4-EVO2 |
| Fire safety class | Class A+A |
| Datasheet | Download Datasheet (PDF) |
Tersedia untuk Proyek EPC
